Torque Sensors
Torque Wrench Calibrator
The Monad MT5H Torque Wrench Calibrator is designed to test torque wrenches up to a maximum capacity of 1500 N•m.
Key specifications
| Brand | Monad |
|---|---|
| Weight | 4 LB (1.8 kgs.) |
| Voltage | 220-240 VAC input available |
| Country of Origin | Made in India |
| Size | 7-1/8" x 4-3/8" x 2" (110x181x50 mm.) |
| Display | Graphics LCD |
| Display Size | 128 x 64 dots |
| Battery | 12 Hours (NiMH 7.2V Rechargeable) |
| Battery Charger | 110-120 VAC 60 Hz 12W input |
| Output | 12 VDC 500mA |
| ADC | 24 bits |
| CPU | 8 bits |
| Communication | RS232C |
| Key Button | 4 Buttons |
| Unit of Measure | 9 User Selectable Torque Units |
| Mode of Measure | 3 Modes |
| Display Digits | 6 Digits maximum |
| Special Function | Auto Reset,Auto Memory,Auto Zero,Go - No Go |
| Memory | 200 readings with alarm when full |
Made in India
Calibrated in-house
Custom ranges
